Description
Specifications | |
Model |
ZD-830 |
Printing Method |
Thermal Line |
Print width |
72mm |
Resolution |
8dots/mm, 203dpi |
Print speed |
260mm/Second |
Interface |
USB |
Line Spacing |
3.75mm(Can be adjusted by command) |
Line No. |
FontA-48Lines/FontB-64Lines |
Character Size |
ANK character,Font A: 1.5×3.0mm(12×24 dots) |
Font B: 1.1×2.1mm(9×17 dots) |
|
Extended character set |
PC437/Katakana/PC850/PC860/PC863/PC865/WestEurope/Greek/Hebrew/EastEurope/Iran/WPC1252/PC866/PC852/PC858/IranII/Latvian/Arabic/PT151,1251/PC737/WPC/1257/ThaiVietnam/PC864/PC1001/(Latvian)/(PC1001)/(PT151,1251)/(WPC1257)/(PC864)/(Vietnam)/(Thai) |
Barcode |
1D bar code: UPC-A/UPC-E/JAN13(EAN13)/JAN8(EAN8)CODE39/ITF/ CODABAR/CODE93/CODE128 |
Graphics printing |
Supports bitmap download and print |
Cutter Function |
Full cut/Half cut |
Paper Width |
79.5±0.5mm |
Paper Roll Diameter |
≤80mm |
Print Commands |
ESC/POS |
Cash Drawer Output |
DC 24V/1A |
Power Adaptor |
Input:AC 100V-240V, 50~60Hz Output:DC 24V/2A |
Printer Dimension |
186*145*140(MM) |
Print Head Life |
100KM |
Cutter Life |
1000,000times |
Driver |
Android, IOS, Linux, Windows |
Working Environment |
Temp:5 ~ 45℃, Humidity:10 ~ 80% |
Storage Environment |
Temp:-10 ~ 50℃, Humidity:10 ~ 90% |
