DATALOGIC DL-Axist 5″ Touch Enterprise Assistant PDA

GENERAL SPECIFICATIONS

• Processor:
  • ARM-7 32 bit 72 MHz
• Operating Platform:
  • Windows CE 6.0
  • Windows Embedded Handheld 6.5 with Mobile tools: Outlook, Word Mobile, Excel Mobile, PowerPoint Mobile, One Note Mobile, and Internet Explorer Mobile 6.0
• Development Environment:
  • Windows SDK
  • Datalogic SDK (C/C++, .Net, Java)
  • Wavelink Studio
  • MCL-Collection™
  • Java Virtual Machine
• Software Utilities:
  • Applications: Pal™ Application Library prelicensed
• Memory:
  • System Flash: 256 MB (including Backup directory for user data & programs permanent storage)
  • System RAM: 256 MB
• Memory Expansion:
  • Micro-SD card slot: Compatible with Micro SD-HC cards, user-accessible
• Scan Options:
  • HIGH PERFORMANCE LASER (HPL):
    • Depth of Field: 1 to 83 cm / 1 to 32 in, depending on barcode and density
    • Scanning Rate: 104 +/- 12 scans/sec.
    • Good Read Feedback: Datalogic’s patented ‘Green Spot‘ technology
  • WDE ASPEDT IMAGER (2D):
    • Depth of Field: 2 to 60 cm / 1 to 24 in, depending on barcode size and density
    • Minimum Resolution: Linear codes: 5 mils; 2D codes: 6.7 mils
    • Good Read Feedback: Datalogic’s patented ‘Green Spot’ technology
  • EXTRA LONG RANGE IMAGER (2D XLR):
    • Depth of Field: 17 to 952 cm / 0.6 to 31.3 ft, depending on barcode size and density
    • Minimum Resolution: Linear codes: 5 mils; 2D codes: 1
• Symbologies supported:
  • Depending on Scan engine used:
    • 1D / linear codes: Auto discriminates all standard 1D codes including GS1 DataBar™ linear codes.
    • 2D Codes: Aztec Code, Data Matrix, MaxiCode, QR Code, UPU FICS, USPS Intelligent Mail
    • Postal codes: Australian Post, Japan Post, KIX Code, PLANET, POSTNET, Royal Mail Code (RM4SCC)
    • Stacked codes: Micro-PDF417, PDF417
• Keyboards:
  • 27-key Numeric or 46-key QWERTY backlit keyboard standard
  • Side scan keys, push to talk, and volume setting
• Audio:
  • Integrated microphone, high-volume speaker
• Display:
  • Reflective TFT daylight readable color display
  • 320 x 240 pixels (CE only) or 640 x 480 (WEHH only)
  • 8.9 cm / 3.5 in diagonal
  • 65K colors, backlight, touch screen
• Camera:
  • Resolution: 3 megapixels
  • Illumination: User controllable flash
  • Lens: Auto focus
• I/O Ports:
  • Main connector with USB 1.1 Host, USB 1.1 Client, RS-232 up to 115.2 Kbps
  • Micro-USB port for power only, no data communication interface
  • Ethernet: via single dock (external module) or multiple cradle
• Radio Options:
  • GLOBAL POSITION SYSTEM (GPS): Assisted GPS (A-GPS) with Skyhook‘s Core Engine hybrid positioning system
  • LOCAL AREA NETWORK (LAN): Summit IEEE 802.11a/b/g
  • PERSONAL AREA NETWORK (PAN): Bluetooth® Wireless Technology IEEE 802.15; Class 2 with EDR
  • WIDE AREA NETWORK (WAN): UMTS HSDPA 850 1900 2100 – GSM/GPRS/ EDGE 850 900 1800 1900 MHz for voice and data communication; SIM socket under the battery
• Battery:
  • Removable battery pack with rechargeable Li-ion high capacity battery included with all models
  • 3.7 V 5000 mAh (18.50 Watt hours); 2820 mAh (10.43 Watt hours) also available
  • Battery Life: Not specified
• Drop Specification:
  • DROP RESISTANCE W
• Environmental Sealing:
  • IP64
• Operating Environment:
  • Operating: -10 to 50 ºC
• Storage Environment:
  • Storage: -20 to 70 ºC
• EMC/Safety Standards:
  • Not specified
• External Dimensions (WxDxH):
  • 15.7 x 8.1 x 4.2 cm / 6.2 x 3.2 x 1.7 in
• Weight:
  • 440.0 g / 15.5 oz including high capacity battery
